Запчасти Komatsu PC800-8K ЦИЛИНДР КОВША Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XP300

CYLINDER GROUP,(FINAL COATING)

|1

707-01-0K300

CYLINDER ASSEMBLY

1

721-13-18010

CYLINDER

2

707-76-11130

BUSHING

3

07145-00110

SEAL,DUST (KIT)

4

07043-00108

PLUG

5

707-27-18180

HEAD,CYLINDER

6

707-51-13030

PACKING,ROD (KIT)

7

707-51-13650

RING,BUFFER (KIT)

8

707-52-91070

BUSHING

9

07179-13136

RING,SNAP

10

707-56-13520

SEAL,DUST (KIT)

11

07179-14146

RING

12

07000-15175

O-RING (KIT)

13

707-35-91840

RING,BACK-UP (KIT)

14

07000-15175

O-RING (KIT)

15

707-35-91840

RING,BACK-UP (KIT)

16

707-71-35060

COLLAR

17

01011-82400

BOLT

18

707-88-75410

WASHER

19

707-58-13280

ROD,PISTON

20

707-76-11130

BUSHING

21

07145-00110

SEAL,DUST (KIT)

22

707-36-18530

PISTON

23

07000-B5120

O-RING (KIT)

24

07001-05120

RING,BACK-UP (KIT)

25

707-44-18920

RING

26

707-39-18510

RING,WEAR (KIT)

27

707-44-18290

RING,PISTON (KIT)

28

707-71-61430

PLUNGER

29

01310-01225

SCREW

30

707-86-13510

TUBE

31

209-63-73582

TUBE

32

07000-13035

O-RING (KIT)

33

07372-21060

BOLT

34

01643-51032

WASHER

35

07000-13038

O-RING

36

07378-11210

HEAD

37

07371-51260

FLANGE

38

01010-81245

BOLT

39

01643-31232

WASHER

40

707-88-26170

BAND

41

707-88-26180

BAND

42

707-88-28450

BRACKET

43

707-88-28440

BRACKET

44

07372-21250

BOLT

45

01643-51232

WASHER

46

07283-33442

CLIP

47

01597-01009

NUT

48

01643-31032

WASHER

|K

707-99-69540

SERVICE KIT
