Запчасти Komatsu PC800-8E0 ГИДРАВЛ DRIFT PREВЕНТИЛЯТОРION КЛАПАН ТРУБЫ, ГЛАВН. ТРУБЫ (/) (№-) ГИДРАВЛ DRIFT PREВЕНТИЛЯТОРION КЛАПАН ТРУБЫ

1

02760-00303

Hose, Face Seal Type

2

02760-00303

Hose, Face Seal Type

3

02754-00328

Hose, Face Seal Type

4

02761-00315

Hose, Face Seal Type

5

20Y-62-22820

Band, Blue

6

20Y-62-22860

Band, Brown

7

04435-52112

Clip

8

04434-51712

Clip

9

04435-51912

Clip

10

01010-81225

Bolt

11

01643-31232

Washer

12

195-979-5190

Collar

13

01011-81230

Bolt

14

01643-31232

Washer

15

01010-81230

Bolt

16

01643-31232

Washer

17

02760-00315

Hose, Face Seal Type

18

02760-00323

Hose, Face Seal Type

19

20Y-62-22790

Band, Red

20

20Y-62-22860

Band, Brown

21

04435-51712

Clip

22

01010-81225

Bolt

23

01643-31232

Washer

24

01010-81250

Bolt

25

01643-31232

Washer

26

195-33-11220

Spacer

27

02754-00348

Hose, Face Seal Type

28

02760-00339

Hose, Face Seal Type

29

20Y-62-22790

Band, Red

30

20Y-62-22820

Band, Blue

31

08034-20834

Band

32

195-49-37150

Bracket

33

01010-81230

Bolt

34

01643-31232

Washer

35

209-62-43330

Bracket

36

21W-62-42420

Nipple

37

02782-10314

Elbow
