Запчасти Komatsu PC800-8E0 НИЖН. ГИДРОЦИЛИНДР КОВША, ПРАВ. (№-) НИЖН. ГИДРОЦИЛИНДР КОВША, .M НИЖН. РАЗГРУЗКА, KMAX TOOTH, ПРЯМАЯ ЛОПАТА CONFIGURATION

|$0

707-01-0C500

Cylinder Assembly

1

707-13-14650

Cylinder

2

707-58-90980

Rod, Piston

3

207-63-76170

Bushing

4

07145-00090

Seal, Dust, (Kit : K14)

5

707-76-90040

Bushing

6

07145-00090

Seal, Dust, (Kit : K14)

7

707-27-14830

Head, Cylinder

8

195-63-94170

Seal, Dust, (Kit : K14)

9

07179-13104

Ring, Snap

10

707-51-90030

Packing, Rod, (Kit : K14)

11

707-51-90640

Ring, Buffer, (Kit : K14)

12

707-52-90681

Bushing

13

707-35-91420

Ring, Back-up, (Kit : K14)

14

07000-15130

O-ring, (Kit : K14)

15

01010-81875

Bolt

16

707-41-11840

Washer

17

707-36-14370

Piston

18

707-44-14180

Ring, Piston, (Kit : K14)

19

707-39-14820

Ring, Wear, (Kit : K14)

20

707-44-14910

Ring

21

707-35-90940

Ring, Back-up, (Kit : K14)

22

07000-15080

O-ring, (Kit : K14)

23

01310-01216

Screw

24

707-86-11890

Block

25

209-62-53630

Tube

26

01435-01060

Bolt

27

07000-13035

O-ring, (Kit : K14)

28

209-62-53670

Bracket

29

209-62-53660

Band

30

01435-01035

Bolt

31

07282-03411

Clamp

32

01435-01020

Bolt

33

01435-01080

Bolt

34

707-88-33040

Cap

35

07371-31049

Flange, Split

36

07372-21035

Bolt

37

01643-51032

Washer

38

07043-00108

Plug, Taper
