Запчасти Komatsu PC800-7-M1 ОСНОВН. НАСОС (8/9) (N. НАСОС) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

708-2L-90740

PUMP ASS'Y

|1

708-25-09470

SERVO VALVE ASS'Y

|1

708-23-00411

BODY ASS'Y

1

BODY,FRONT

2

EXPANDER

3

708-25-15120

PISTON

4

708-25-15130

SEAT

5

708-25-55250

SPRING

6

708-25-25130

SPRING

7

708-23-15160

PLUG

8

708-23-15120

SEAT

9

07000-12018

O-RING

10

708-25-15150

COVER

11

01580-10806

NUT

12

01252-60616

BOLT

13

01602-20619

WASHER

14

07002-12034

O-RING

15

07239-12009

NUT

16

708-25-15180

SLEEVE

17

708-25-15280

SPOOL

18

708-25-15310

SPRING

19

708-25-15330

SPACER

20

708-25-15171

PLUG

21

708-25-15340

SCREW

22

07000-12012

O-RING

23

708-25-15250

COVER

24

01580-10806

NUT

25

01252-60616

BOLT

26

01602-20619

WASHER

27

708-25-15260

PLUG

28

07002-10823

O-RING

29

708-25-15270

ARM

30

708-25-15360

PIN

31

708-25-15370

WASHER

32

708-25-15380

E-RING

33

07040-11007

PLUG

34

07002-11023

O-RING

35

708-25-55110

PLATE

36

708-25-19290

PLUG

37

07000-12010

O-RING

38

07000-12011

O-RING

39

01010-80825

BOLT

40

01643-50823

WASHER

41

708-25-19150

ORIFICE

42

720-68-11920

FILTER

43

07000-12010

O-RING

44

07000-11009

O-RING

45

07000-13048

O-RING

46

708-25-15430

PLUG

47

708-25-15460

SHIM¤ 0.05MM

|47

708-25-15470

SHIM¤ 0.10MM
