Запчасти Komatsu PC800-6 ОСНОВН. КЛАПАН (4-Х СЕКЦИОНН.) (/)(№-999) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$5

709-14-93602

CONTROL VALVE

|$6

709-14-93601

CONTROL VALVE

|$7

709-14-93600

CONTROL VALVE

|$8

709-14-93301

CONTROL VALVE

|$9

709-14-93300

CONTROL VALVE

|$16

BODY GROUP ASS'Y

|$17

BODY GROUP ASS'Y

|$18

BODY GROUP ASS'Y

|$19

BODY GROUP ASS'Y

|$20

BODY GROUP ASS'Y

1

BODY,VALVE

2

SPOOL

3

SPOOL SUB ASS'Y

3

SPOOL SUB ASS'Y

3

SPOOL SUB ASS'Y

3

SPOOL

4

SPOOL SUB ASS'Y

4

SPOOL

5

SPOOL

6

700-22-11370

PLUG

7

07002-12434

O-RING

8

709-14-11510

PLUG

9

700-80-61260

O-RING

10

700-80-61430

RING

11

700-94-11260

PLUG

12

07002-13634

O-RING

13

07000-12018

O-RING

14

07001-02018

RING,BACK-UP

15

709-14-11520

CASE

16

709-14-11530

RETAINER

17

709-14-11550

SPRING

18

709-14-11560

SPRING

19

07000-12065

O-RING

19

07000-02065

O-RING

20

01252-61035

BOLT

21

709-12-11411

VALVE,CHECK

22

709-14-11840

VALVE,CHECK

23

709-12-11430

SPRING

24

709-14-11721

SPRING
