Запчасти Komatsu PC800-6 ОСНОВН. НАСОС (/) (NO. НАСОС)(№-7) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

708-2L-00311

PUMP ASS'Y

|$3

708-25-09250

SERVO VALVE ASS'Y,REAR

|$4

708-25-09650

VALVE ASS'Y,CO AND NC

|$5

708-23-00441

BODY ASS'Y

1

BODY

2

EXPANDER

3

708-25-17460

PLUG

4

708-25-17430

SCREW

5

07000-02010

O-RING

6

708-25-17131

COVER

7

01580-10806

NUT

8

708-25-17141

SPOOL

9

708-25-17150

SLEEVE

10

708-25-17160

PISTON

11

708-25-17170

COVER

12

07000-02014

O-RING

13

708-25-17180

SEAT

14

708-25-17690

SPRING

15

708-25-17220

PISTON

16

708-25-17370

SEAT

17

708-25-17250

SPRING

18

708-25-17470

SEAT

19

708-23-17290

COVER

20

07000-03028

O-RING

21

708-25-17380

PLUG

22

708-25-15340

SCREW

23

07000-02021

O-RING

24

708-23-17240

COVER

25

708-25-17480

PISTON

26

706-75-40310

BOLT

27

01602-20619

WASHER

28

708-25-15320

BOLT

29

01602-20619

WASHER

30

01580-10806

NUT

31

07000-12012

O-RING

32

07001-02012

RING,BACK-UP

33

708-25-17451

SLEEVE

34

07000-02012

O-RING

35

708-25-15320

BOLT

36

01602-20619

WASHER

37

07000-12021

O-RING

38

07001-02021

RING,BACK-UP

39

07000-02018

O-RING

40

07000-11009

O-RING

41

07000-02011

O-RING

42

708-23-18241

PLATE

43

07040-11007

PLUG

44

07002-11023

O-RING

45

07040-11409

PLUG

46

07002-11423

O-RING

47

01010-80830

BOLT

48

01602-20825

WASHER
