Запчасти Komatsu PC800-6 ОСНОВН. НАСОС (/) (NO. НАСОС)(№7-999) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

708-2L-00620

PUMP ASS'Y

|$3

708-25-09270

VALVE ASS'Y,SERVO

|$4

708-25-00820

BODY ASS'Y

1

BODY

2

EXPANDER

3

708-25-55260

PISTON

4

708-25-15130

SEAT

5

708-25-55250

SPRING

6

708-25-25130

SPRING

7

708-23-15160

PLUG

8

708-23-15120

SEAT

9

07000-02018

O-RING

10

708-25-15150

COVER

11

01580-10806

NUT

12

708-25-15320

BOLT

13

01602-20619

WASHER

14

07002-02034

O-RING

15

07239-12009

NUT

16

708-25-15180

SLEEVE

17

708-25-15280

SPOOL

18

708-25-15310

SPRING

19

708-25-15330

SPACER

20

708-25-15171

PLUG

21

708-25-15340

SCREW

22

07000-02012

O-RING

23

708-25-15250

COVER

24

01580-10806

NUT

25

708-25-15320

BOLT

26

01602-20619

WASHER

27

708-25-15260

PLUG

28

07002-00823

O-RING

29

708-25-15270

ARM

30

708-25-15360

PIN

31

708-25-15370

WASHER

32

708-25-15380

E-RING

33

07040-11007

PLUG

34

07002-01023

O-RING

35

708-25-55240

PLATE

36

708-25-19290

PLUG

37

07000-12010

O-RING

38

07000-02011

O-RING

39

01010-80825

BOLT

40

01643-50823

WASHER

41

708-25-19150

ORIFICE

42

720-68-11920

FILTER

43

07000-12010

O-RING

44

07000-11009

O-RING

45

07000-03048

O-RING

46

708-25-15430

PLUG

47

708-25-15460

SHIM, 0.05MM

47

708-25-15470

SHIM, 0.10MM
