Запчасти Komatsu PC800-6 КАБИНА (ОСНОВ.) (РЫЧАГ С КЛАПАНОМ PPC)(№-999) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

207-06-61510

BASE

2

20Y-06-24120

SWITCH ASS'Y,Y

3

01641-21223

WASHER

4

569-06-61960

RELAY

5

01435-00610

BOLT

6

207-06-61112

WIRING HARNESS

|6

207-06-61111

WIRING HARNESS

7

205-06-73180

FUSE¤ 15A

8

283-06-16110

BOX

9

195-Z11-2290

COVER

10

283-06-16190

FUSE¤ 10A

11

22W-06-13160

FUSE¤ 20A

12

20Y-06-24130

SWITCH

13

20Y-06-24270

CLIP

14

20Y-06-21460

CLIP

15

20Y-06-23960

CLIP

16

01023-10625

SCREW

17

20Y-979-2130

BOX ASS'Y,(SEE FIG. Y1979-61A0)

18

01435-01016

BOLT

19

20Y-979-2221

DUCT

20

01435-00610

BOLT

21

20Y-979-2231

DUCT

22

01435-00610

BOLT

23

20Y-979-2242

DUCT

24

01435-00610

BOLT

25

7861-94-3000

RESISTOR

|25

20Y-06-17220

RESISTOR

26

01435-00820

BOLT

27

203-06-56230

BUZZER ASS'Y

28

01435-00610

BOLT

29

7834-22-2003

CONTROLLER¤PGC

|29

7834-22-2002

CONTROLLER

|29

7834-22-2001

CONTROLLER

|29

7834-22-2000

CONTROLLER

30

01435-00880

BOLT

31

20Y-06-24410

CONTROLLER

32

01435-00630

BOLT

33

08051-00801

CLIP

34

20Y-06-23521

LOCK

35

01435-00820

BOLT

36

20Y-06-24220

SHEET

37

209-06-72111

WIRING HARNESS

38

08034-00519

BAND

39

569-06-61960

RELAY

40

01435-00610

BOLT
