Запчасти Komatsu PC80-1 ТОРМОЗНОЙ КЛАПАН ПОВОРОТН. СИСТЕМА

|$0

706-73-07700

SWING MOTOR ASS'Y,(KMF40DS)

|$$2

|$2

706-73-72500

VALVE ASS'Y,BRAKE

1

BODY,VALVE

2

SPOOL

3

706-73-70140

VALVE

4

706-73-70150

SPRING

5

706-73-70161

PLUG

6

706-73-71150

RING

7

706-73-71140

SPRING

8

706-73-71510

CASE

9

702-15-35140

RETAINER

10

706-75-77131

SPRING

11

706-73-71440

PLATE

12

07002-11623

O-RING

13

07000-13035

O-RING

14

07000-12010

O-RING

15

01010-31075

BOLT

16

01602-01030

WASHER,SPRING

17

706-73-71390

SPOOL

18

706-73-71360

PLATE

19

706-73-71380

SPRING

20

07040-13016

PLUG

21

07002-13034

O-RING

22

706-73-71370

SPOOL

23

706-73-77140

PLATE

24

706-75-77150

SPRING

25

706-73-71470

PLUG

26

07002-12434

O-RING

27

07000-12016

O-RING

28

07001-02016

RING

29

706-73-71460

PLUG

30

07002-12034

O-RING

31

07000-12010

O-RING

32

07001-02010

RING,BACK-UP

33

706-73-71450

PLUG

34

07002-11423

O-RING

35

07040-10807

PLUG

36

07002-10823

O-RING

37

07040-11409

PLUG

38

07002-11423

O-RING

|$41

706-73-76600

VALVE ASS'Y,C.O.R.

39

SLEEVE

40

SEAT,VALVE

41

07000-22016

O-RING

42

07001-02016

RING,BACK-UP

43

VALVE

44

SPRING

45

PISTON

46

O-RING

47

RING,BACK-UP

48

SCREW

49

NUT

50

07000-12021

O-RING

51

07001-02021

RING,BACK-UP

52

07002-13034

O-RING
