Запчасти Komatsu PC78UU-8 OFFSET СТРЕЛА, ПАЛЕЦ (№-) OFFSET СТРЕЛА, ДЛЯ OFFSET СТРЕЛА, -НАВЕСН. ОБОРУД

1

20X-70-31230

Shaft

2

205-70-66580

Plate

3

01010-81230

Bolt

4

01643-31232

Washer

5

21W-70-21230

Shim, T=2.5mm

6

21W-70-21540

Pin

7

205-70-66580

Plate

8

21W-70-21661

Plate

9

01010-81230

Bolt

10

01643-31232

Washer

11

20S-70-81740

Spacer, T=0.5mm

12

21W-70-41560

Spacer, T=1.0mm

13

21W-70-21240

Pin

14

21W-70-55230

Plate

15

01010-81230

Bolt

16

01643-31232

Washer

17

21Y-70-14710

Spacer, T=1.0mm

18

07020-00900

Fitting, Grease

19

21W-70-21261

Pin

20

20T-70-71591

Plate

21

01010-81230

Bolt

22

01643-31232

Washer

23

21W-70-21230

Shim, T=2.5mm

24

22J-46-11120

Cap

|$24

21W-70-21371

Pin

25

21W-70-21371

Pin

26

04082-00212

Lock

27

01010-81230

Bolt

28

01643-31232

Washer

29

20T-70-81770

Spacer, T=1.0mm

30

22L-46-12150

Cap

31

21W-70-21430

Pin

32

04082-00212

Lock

33

01010-81230

Bolt

34

01643-31232

Washer

35

22C-70-31510

Spacer, T=1.0mm
