Запчасти Komatsu PC78UU-8 ПРОПОРЦИОНАЛЬН. PRESSURE УПРАВЛ-Е (PPC) КЛАПАН ТРУБЫ, ОСНОВН. ТРУБЫ (/) (№-) ПРОПОРЦИОНАЛЬН. PRESSURE УПРАВЛ-Е (PPC) КЛАПАН ТРУБЫ, -WAY SHIFT PATTERN ШЛАНГИ CHANGE ТИП

1

21W-62-55741

Hose Assembly

2

Hose

3

Hose

4

Hose

5

Hose

6

Hose

7

Hose

8

Hose

9

Hose

10

Hose

11

20U-62-22190

O-ring

11

21W-60-43200

Valve Assembly

12

21W-62-43930

Nipple

13

21W-62-44750

Body

14

21W-62-42940

Nipple

15

07002-11423

O-ring

16

02896-11008

O-ring

17

21U-62-34770

Band, White

18

21U-62-34750

Band, Blue

19

21U-62-34720

Band, Black

20

21U-62-34730

Band, Green

21

21U-62-34720

Band, Black

22

21U-62-34710

Band, Yellow

23

21U-62-34780

Band, Brown

24

21U-62-34770

Band, White

25

21U-62-34710

Band, Yellow

26

21U-62-34720

Band, Black

27

21U-62-34750

Band, Blue

28

21U-62-34730

Band, Green

29

21U-62-34760

Band, Red

30

21U-62-34720

Band, Black

31

21W-62-51301

Hose Assembly

32

21W-62-51330

Hose

33

21W-62-51320

Hose

34

21W-62-51310

Hose

35

21U-62-34710

Band, Yellow

36

21U-62-34730

Band, Green

37

21U-62-34760

Band, Red

38

21U-62-34710

Band, Yellow

39

21U-62-34760

Band, Red

40

21W-62-55811

Hose Assembly

41

21W-62-55840

Hose

42

21W-62-55821

Hose

43

21W-62-55831

Hose

44

21U-62-34710

Band, Yellow

45

21U-62-34730

Band, Green

46

21U-62-34720

Band, Black

47

02761-002A4

Hose, Face Seal Type
