Запчасти Komatsu PC78UU-8 РУКОЯТЬ И КОВШ ТРУБЫ (№-) РУКОЯТЬ И КОВШ ТРУБЫ, С -ДОПОЛН. АКТУАТОР ТРУБЫ

1

21W-62-42411

Nipple

2

07002-11823

O-ring

3

02896-11009

O-ring

4

21W-62-42420

Nipple

5

07002-11823

O-ring

6

02896-11009

O-ring

7

02781-00425

Union

8

07002-12434

O-ring

9

02896-11012

O-ring

10

21W-62-42481

Nipple

11

07002-12434

O-ring

12

02896-11015

O-ring

13

02781-00422

Union

14

07002-12034

O-ring

15

02896-11012

O-ring

16

21W-62-43691

Hose, Green

17

21W-62-43711

Hose, Orange

18

21W-62-43721

Hose, Red

19

21W-62-55151

Hose, Black-White

20

21W-62-43740

Hose, Blue

21

21W-62-55141

Hose, Red-White

22

21U-62-34730

Band, Green

23

21U-62-34740

Band, Orange

24

21U-62-34760

Band, Red

25

21U-62-34770

Band, White

26

21U-62-34720

Band, Black

27

21U-62-34750

Band, Blue

28

21U-62-34770

Band, White

29

21U-62-34760

Band, Red

30

21W-62-55211

Clamp

31

21W-62-55260

Rubber

32

21W-62-55270

Rubber

33

01010-81235

Bolt

34

01643-31232

Washer

35

08034-20519

Band

36

21W-62-55240

Plug

37

21W-62-41921

Hose

|$37

21W-62-41921

Hose
