Запчасти Komatsu PC78UU-8 ПОРШЕНЬ НАСОС, ВНУТР. ЧАСТИ (/) (№-) ПОРШЕНЬ НАСОС

Схема запчастей Komatsu PC78UU-8 - ПОРШЕНЬ НАСОС, ВНУТР. ЧАСТИ (/) (№-) ПОРШЕНЬ НАСОС
5
1
2
3
4
15
20
9
6
7
10
11
12
13
19
14
16
17
18
26
30
28
27
24
29
25
21
22
23
32
38
39
40
8
2
2
31
2
5
36
34
35
33
32
37

Артикул

Название

Примечание

Количество

|$0

708-3T-00273

Pump Assembly

|$1

708-3T-03271

Valve Assembly

|$2

708-3T-03270

Valve Assembly, Servo

|$3

708-3T-04360

Body Assembly

1

Body

2

Plug

2

708-3T-04320

Piston Subassembly

3

Piston

4

Sleeve

5

708-1S-15390

Seal

5

708-3T-04340

Piston Subassembly

6

Piston

7

Plug

8

708-1S-15390

Seal

9

07002-11623

O-ring

10

708-3T-15280

Spool

11

708-3T-15310

Seat

12

708-3T-15410

Spring

13

708-3T-15290

Retainer

14

708-3T-15250

Plug

15

07000-11006

O-ring

16

01583-11207

Nut

17

708-3T-15260

Lever

18

708-1S-15280

Spacer

19

07002-11623

O-ring

20

708-1S-15290

Plug

21

708-3T-15560

Plug

22

07002-11223

O-ring

23

708-3T-03711

Spool Subassembly

24

708-3T-15521

Plug

25

07000-11008

O-ring

26

07001-01008

Ring, Back-up

27

01583-51408

Nut

28

708-3T-15530

Spring

29

708-1S-15350

Seat

30

708-1S-15360

Seat

31

708-3T-15811

Orifice

32

702-21-60700

Valve, Pilot

32

702-21-57400

Valve, Pilot

33

700-80-61260

O-ring

34

723-11-19960

O-ring

35

702-21-54180

Screw

36

702-16-55610

O-ring

36

702-21-54910

O-ring

37

01252-60635

Bolt, Hexagon Socket Head

38

708-8E-16150

Plug

39

07002-11023

O-ring

40

20B-27-11210

Bleeder

Выбрано товаров: 48
