Запчасти Komatsu PC78UU-6 P.P.C ОСНОВН. ЛИНИЯ (/) ГИДРАВЛИКА

Схема запчастей Komatsu PC78UU-6 - P.P.C ОСНОВН. ЛИНИЯ (/) ГИДРАВЛИКА
1
1
2
3
3
4
4
5
5
6
6
7
7
7
8
8
9
9
10
10
11
11
12
13
14
15
15
16
17
18
19
20
20
21
22
22
23
23
24
24
25
25
26
27
27
28
28
29
29
30
31
32
33
33
34
35
36
36
37
38
39
39

Артикул

Название

Примечание

Количество

1

21W-62-41411

HOSE, 2010MM,BLUE-YELLOW

1

21U-62-34750

BAND, BLUE

1

21U-62-34710

BAND, YELLOW

2

20U-62-22190

O-RING

3

21W-62-41480

HOSE, 1860MM,ORANGE-YELLOW

3

21U-62-34740

BAND, ORANGE

3

21U-62-34710

BAND, YELLOW

4

21W-62-41480

HOSE, 1860MM,GREEN-YELLOW

4

21U-62-34730

BAND, GREEN

4

21U-62-34710

BAND, YELLOW

5

21W-62-41511

HOSE,WHITE-RED

5

21U-62-34770

BAND, WHITE

5

21U-62-34760

BAND, RED

6

21W-62-41771

HOSE, 1650MM,BLACK-GREEN

6

21U-62-34720

BAND, BLACK

6

21U-62-34730

BAND, GREEN

7

21W-62-41441

HOSE, 2050MM,BROWN

7

21U-62-34780

BAND, BROWN

8

21W-62-41531

HOSE, 2030MM,YELLOW

8

21U-62-34710

BAND, YELLOW

9

21W-62-41581

HOSE, 2270MM,ORANGE

9

21U-62-34740

BAND, ORANGE

10

21W-62-41610

HOSE, 2260MM,RED

10

21U-62-34760

BAND, RED

11

21W-62-41761

HOSE, 1460MM,BLACK-BLUE

11

21U-62-34720

BAND, BLACK

11

21U-62-34750

BAND, BLUE

12

21W-62-43930

NIPPLE

13

21W-62-44750

BODY

14

21W-62-42940

NIPPLE

15

07002-11423

O-RING

16

21W-62-43380

NIPPLE

17

21W-62-42940

NIPPLE

18

02896-11008

O-RING

19

07002-11423

O-RING

20

08210-00606

SPIRAL TUBE

21

08210-01204

SPIRAL TUBE

22

21W-62-41551

HOSE, 2280MM,BLACK

22

21U-62-34720

BAND, BLACK

23

21W-62-41571

HOSE,GREEN

23

21U-62-34730

BAND, GREEN

24

21W-62-41590

HOSE, 2350MM,BLUE

24

21U-62-34750

BAND, BLUE

25

21W-62-41421

HOSE, 1990MM,RED-BLACK

25

21U-62-34760

BAND, RED

25

21U-62-34720

BAND, BLACK

26

20U-62-22190

O-RING

27

21W-62-41451

HOSE, 1950MM,BROWN-YELLOW

27

21U-62-34780

BAND, BROWN

27

21U-62-34710

BAND, YELLOW

28

21W-62-41470

HOSE, 1930MM,BLACK-YELLOW

28

21U-62-34720

BAND, BLACK

28

21U-62-34710

BAND, YELLOW

29

21W-62-41491

HOSE, 1900MM,WHITE-BLACK

29

21U-62-34770

BAND, WHITE

29

21U-62-34720

BAND, BLACK

30

21W-62-43930

NIPPLE

31

21W-62-44750

BODY

32

21W-62-42940

NIPPLE

33

07002-11423

O-RING

34

21W-62-43380

NIPPLE

35

21W-62-42940

NIPPLE

36

02760-00221

HOSE,WHITE

36

21U-62-34770

BAND, WHITE

37

02896-11008

O-RING

38

07002-11423

O-RING

39

08210-00606

SPIRAL TUBE

Выбрано товаров: 67
