Запчасти Komatsu PC78UU-6 МОТОР ХОДА (/) (КОНЕЧНАЯ ПЕРЕДАЧА) (GM9VN ТИП) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

21W-60-41201

MOTOR ASS'Y

|$3

TZ507D1000-02

FINAL DRIVE ASS'Y

|$4

SPINDLE KIT

|$5

SPINDLE ASS'Y

1

SPINDLE

2

FLANGE,END

3

TZ500D1019-00

BOLT,REAMER

|$9

RV GEAR

|$10

TZ500D1204-00

RV GEAR KIT

4

RV GEAR

5

RV GEAR

6

SHAFT,CRANK

7

SPACER

8

BEARING

9

BEARING

|$17

TZ507D1107-00

SPUR GEAR KIT

10

SPUR GEAR

|$19

TZES20423232-B

FLOATING SEAL ASS'Y

11

TZES100-204-B

SEAL,FLOATING (KIT)

12

TZ507D1001-00

HUB,MOTOR

13

TZ507D1006-00

GEAR

14

TZ500D1008-00

COVER

15

TZ500D1015-00

SHAFT

16

TZ500D1017-00

PIN

17

TZ810B1018-00

RING

18

SNAP RING SET

19

TZ500D1021-00

BEARING

20

TZJB2804-S19

RING,SNAP

21

04064-02512

RING,SNAP

22

07000-11008

O-RING (KIT)

23

07000-15230

O-RING (KIT)

24

TZJW1516-G35-7

O-RING (KIT)

25

TZ410D1033-01

PLUG

26

TZ810B2021-00

PLUG

27

07000-12014

O-RING (KIT)

28

04260-00952

BALL

29

TZJ1354-8-22

PIN

K

TZ505D9000-00

SEAL KIT,TRAVEL MOTOR
