Запчасти Komatsu PC78UU-6 ЦИЛИНДР РУКОЯТИ(ВНУТР. ЧАСТИ) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

707-02-X0062

CYLINDER GROUP,(VIOLET BLUE)

G1

707-02-X7960

CYLINDER GROUP,(VIOLET BLUE)

G1

707-02-X0061

CYLINDER GROUP,(VIOLET BLUE)

G1

707-02-X0060

CYLINDER GROUP,(VIOLET BLUE)

G1

707-02-X0052

CYLINDER GROUP,(NATURAL YELLOW)

G1

707-02-X8010

CYLINDER GROUP,(NATURAL YELLOW)

G1

707-02-X0051

CYLINDER GROUP,(NATURAL YELLOW)

G1

707-02-X0050

CYLINDER GROUP,(NATURAL YELLOW)

|$9

707-02-00061

CYLINDER GROUP,ARM

|$10

707-02-00060

CYLINDER ASS'Y,ARM

1

707-12-11130

CYLINDER

2

707-76-65551

BUSHING

2

707-76-65550

BUSHING

3

07145-00065

SEAL,DUST (KIT)

4

707-58-65890

ROD,PISTON

5

707-76-60721

BUSHING

5

707-76-60720

BUSHING

6

07145-00060

SEAL,DUST (KIT)

7

07020-00000

FITTING,GREASE

8

707-29-11751

HEAD,CYLINDER

9

144-63-92170

SEAL,DUST (KIT)

10

07179-12079

RING,SNAP

11

707-52-10661

BUSHING

12

707-51-65211

PACKING,ROD (KIT)

13

07000-12110

O-RING (KIT)

14

707-35-91140

RING,BACK-UP (KIT)

15

07000-12105

O-RING (KIT)

16

707-36-11270

PISTON

17

707-44-11180

RING,PISTON (KIT)

18

07156-01112

RING,WEAR (KIT)

19

707-71-60050

PLUNGER

20

04260-00635

BALL

21

707-71-91290

PLUG

22

707-67-48010

NUT

23

02896-11012

O-RING (KIT)

24

02896-11015

O-RING (KIT)

25

707-86-46960

TUBE

26

707-86-55081

TUBE

26

707-86-55080

TUBE

27

01010-81020

BOLT

28

01643-31032

WASHER

29

02896-11012

O-RING (KIT)

30

02896-11015

O-RING (KIT)

K

707-98-36720

SERVICE KIT,ARM CYLINDER

K

707-98-36710

SERVICE KIT,ARM CYLINDER
