Запчасти Komatsu PC78UU-6 ОСНОВН. НАСОС (/)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$3

708-3T-00217

PUMP ASS'Y

|$4

708-3T-00216

PUMP ASS'Y

|$5

708-3T-00215

PUMP ASS'Y

|$7

708-3T-01116

PUMP SUB ASS'Y

|$8

708-3T-01115

PUMP SUB ASS'Y

|$9

708-3T-01114

PUMP SUB ASS'Y

|$10

708-3T-04130

CYLINDER BLOCK ASS'Y

1

BLOCK,CYLINDER

2

PLATE,VALVE

3

708-1W-23130

SEAT

4

708-3T-13150

SPRING

5

04065-04218

RING,SNAP

6

708-3T-13351

GUIDE,RETAINER

7

708-3T-13360

PIN

8

708-3T-13340

RETAINER,SHOE

9

708-3T-13312

PISTON SUB ASS'Y

9

708-3T-13311

PISTON SUB ASS'Y

|$21

708-3T-04111

FLANGE ASS'Y

10

FLANGE

11

PLUG

12

708-3T-13421

BALL

13

708-3T-13412

CAM,ROCKER

13

708-3T-13411

CAM,ROCKER

14

708-3T-13451

STUD,BALL

15

04020-01024

PIN

16

01252-61235

BOLT

17

07000-B2012

O-RING

18

708-7T-51210

O-RING

19

708-3T-14222

PLUG

20

07000-12010

O-RING

21

01643-51232

WASHER

22

01582-11210

NUT

23

708-3T-14114

PISTON SUB ASS'Y

23

708-3T-14113

PISTON SUB ASS'Y

24

708-3T-14120

SPRING

25

708-3T-12150

IMPELLER

26

708-3T-12160

COUPLING

27

708-3T-12410

SCREW

28

01640-20508

WASHER

29

708-3T-12420

PLATE

30

708-3T-05110

SHIM KIT

30

SHIM, 0.1MM

30

SHIM, 0.15MM

30

SHIM, 0.2MM

30

SHIM, 0.5MM

31

708-23-12350

SCREW
