Запчасти Komatsu PC78UU-6 СОЕДИНЕНИЕ КОВША (YELНИЗ.) РАБОЧЕЕ ОБОРУДОВАНИЕ

1

21W-70-44290NK

LINK,L.H.

1

21W-70-44290SA

LINK (YELLOW),L.H.

1

201-70-64140SA

LINK (YELLOW),L.H.

2

21W-70-44280NK

LINK,R.H.

2

21W-70-44280SA

LINK (YELLOW),R.H.

2

201-70-64130SA

LINK (YELLOW),R.H.

|$23

201-70-00823

LINK ASS'Y,R.H.

|$24

201-70-00822

LINK ASS'Y,R.H.

|$25

201-70-00821

LINK ASS'Y,R.H.

3

LINK (YELLOW),R.H.

3

LINK,R.H.

3

LINK (YELLOW),R.H.

4

21W-70-41371

BUSHING

4

21W-70-41370

BUSHING

5

21W-70-41381

BUSHING

5

21W-70-41380

BUSHING

6

21W-70-41440

SEAL

7

21W-70-41450

SEAL

8

07020-00900

FITTING,GREASE

9

07020-00000

FITTING,GREASE

|$42

201-70-00813

LINK ASS'Y,L.H.

|$43

201-70-00812

LINK ASS'Y,L.H.

|$44

201-70-00811

LINK ASS'Y,L.H.

10

LINK (YELLOW),L.H.

10

LINK,L.H.

10

LINK (YELLOW),L.H.

11

21W-70-41371

BUSHING

11

21W-70-41370

BUSHING

12

21W-70-41381

BUSHING

12

21W-70-41380

BUSHING

13

21W-70-41440

SEAL

14

21W-70-41450

SEAL

15

07020-00900

FITTING,GREASE

16

07020-00000

FITTING,GREASE

17

21W-70-42170NK

SHAFT

17

21W-70-42170SA

SHAFT (YELLOW)

18

21W-70-42180NK

SHAFT

18

21W-70-42180SA

SHAFT (YELLOW)

19

07020-00000

FITTING,GREASE

20

01011-81620

BOLT

21

01580-11613

NUT

22

21Y-70-14770

SPACER, 1.0MM

23

21Y-70-14780

SPACER, 2.0MM

24

22C-70-31510

SPACER, 1.0MM
