Запчасти Komatsu PC78UU-6 РУКОЯТЬ (ТРУБЫ) (ДЛЯ НАВЕСН. ОБОРУД.) (YELНИЗ.) РАБОЧЕЕ ОБОРУДОВАНИЕ

1

21W-973-4710NK

TUBE

1

21W-973-4710SA

TUBE (YELLOW)

2

02896-11018

O-RING

3

21W-973-4720NK

TUBE

3

21W-973-4720SA

TUBE (YELLOW)

4

02896-11012

O-RING

5

22B-62-19410NK

CLAMP

5

203-62-43370

CLAMP

6

203-62-43380

CUSHION

7

21W-70-41850NK

CLAMP

7

203-62-43360

CLAMP

8

203-62-43380

CUSHION

9

203-62-43390

CUSHION

10

01010-81270

BOLT

11

01643-31232

WASHER

|$23

203-973-5803

VALVE ASS'Y

12

07000-13031

O-RING

13

04025-00412

PIN

14

04064-03015

RING

15

203-973-3913

BODY

16

203-973-3923

SHAFT

17

07000-13025

O-RING

18

203-973-6610

MAT

19

01010-80825

BOLT

20

01643-30823

WASHER

21

21T-72-14930

BOSS

22

01010-81020

BOLT

23

01643-31032

WASHER

24

203-973-5730

ELBOW

25

07002-13334

O-RING

26

20D-973-3350

NIPPLE

27

20D-973-3360

PLUG

28

21W-973-4550

NIPPLE

29

07002-13334

O-RING

30

02896-11012

O-RING

31

21W-973-4560

NIPPLE

32

07002-13334

O-RING

33

02896-11018

O-RING
