Запчасти Komatsu PC78UU-6 СТРЕЛА (НАВЕСН. ОБОРУД ТРУБЫ) (ATT¤YELНИЗ.)(№-) РАБОЧЕЕ ОБОРУДОВАНИЕ

1

21W-973-4391NK

TUBE

1

21W-973-4391SA

TUBE (YELLOW)

2

02896-11012

O-RING

3

21W-973-4361NK

TUBE

3

21W-973-4361

TUBE

4

02896-11018

O-RING

5

21W-70-41850NK

CLAMP

5

203-62-43360

CLAMP

6

203-62-43380

CUSHION

7

203-62-43390

CUSHION

8

01010-81270

BOLT

9

01643-31232

WASHER

10

22B-62-19410NK

CLAMP

10

203-62-43370

CLAMP

11

203-62-43380

CUSHION

12

203-62-43390

CUSHION

13

01010-81265

BOLT

14

01643-31232

WASHER

15

21W-973-4370

HOSE

16

21W-973-4380

HOSE

17

21W-973-4051

BRACKET

17

21W-973-4050SA

BRACKET (YELLOW)

18

21W-973-4352NK

TUBE

18

21W-973-4352SA

TUBE (YELLOW)

18

21W-973-4351

TUBE

19

02896-11012

O-RING

20

21W-973-4342NK

TUBE

20

21W-973-4342SA

TUBE (YELLOW)

20

21W-973-4341

TUBE

21

02896-11018

O-RING

22

22B-62-19410NK

CLAMP

22

203-62-43370

CLAMP

23

203-62-43380

CUSHION

24

203-62-43390

CUSHION

25

01010-81270

BOLT

25

01010-81265

BOLT

26

01643-31232

WASHER

27

22B-62-19410NK

CLAMP

27

203-62-43370

CLAMP

27

203-62-43360

CLAMP

28

203-62-43380

CUSHION

29

203-62-43390

CUSHION

30

01010-81270

BOLT

30

01010-81265

BOLT

31

01643-31232

WASHER

32

21W-973-4982NK

BRACKET

32

21W-973-4981SA

BRACKET (YELLOW)

33

01010-81235

BOLT

34

01643-31232

WASHER

35

21W-70-41860NK

BRACKET

35

20U-973-2290

BRACKET

36

01010-81235

BOLT

37

01643-31232

WASHER

38

21W-973-5890

HOSE

38

02765-B0421

HOSE

38

21W-973-4960

HOSE

39

21W-973-4972

HOSE

39

21W-973-4971

HOSE

39

21W-973-4970

HOSE

40

08034-40521

BAND
