Запчасти Komatsu PC78UU-6 ПРАВ. COVER ЧАСТИ КОРПУСА

|1

21W-46-41601

COVER ASS'Y

|1

21W-46-41600

COVER ASS'Y

1

21W-46-41612NW

COVER

|1

21W-46-41611NW

COVER

2

21W-46-41621NW

COVER

3

21W-46-41630

HINGE

4

01010-81225

BOLT

5

01643-31232

WASHER

6

21W-46-41641

SEAL

7

21W-46-41651

BAR

8

04052-11038

PIN,SNAP

9

01643-31032

WASHER

10

21W-46-41660

GROMMET

11

21W-46-41670

BRACKET

12

01010-80620

BOLT

13

01643-30623

WASHER

14

21W-46-41690

SHEET

15

21W-46-41710

LOCK ASS'Y

16

01010-81020

BOLT

17

01643-31032

WASHER

18

21W-46-41740

SEAL

19

21W-46-41750

LOCK ASS'Y

20

21W-54-41361

ROD

21

01643-30823

WASHER

22

04052-10833

PIN,SNAP

23

20R-54-11460

SPRING

24

01023-10512

SCREW

25

08037-02512

GROMMET

26

20B-54-12210

SPRING

27

01023-10410

SCREW

28

20Y-54-11611

STOPPER

29

01580-11008

NUT

30

566-54-11340

GROMMET

|30

08037-02512

GROMMET

31

21W-46-41780

SHEET

32

01010-81230

BOLT

33

130-43-64260

COLLAR

34

01010-81270

BOLT

35

01643-31232

WASHER

36

113-03-21160

SEAT

37

515-02-11330

BUSHING

38

566-35-42430

PLATE

39

07000-12016

O-RING

40

01010-81240

BOLT

41

01643-31232

WASHER

42

419-54-11270

SPACER

43

566-35-42430

PLATE
