Запчасти Komatsu PC78UU-6 ПОКРЫТИЕ ПОЛА (НАВЕС)(№-) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|1

21W-54-43300

COVER ASS'Y

1

COVER

2

21W-54-43650

SEAL

3

01010-81025

BOLT

4

01643-31032

WASHER

5

21W-54-43261

BRACKET

6

01010-81025

BOLT

7

01643-31032

WASHER

8

566-35-42430

PLATE

9

203-62-42770

CUSHION

10

21W-62-11620

SPACER

11

01010-81250

BOLT

12

01643-31232

WASHER

|13

21W-54-43501

COVER ASS'Y

13

COVER

14

21W-54-43520

SEAL

15

21W-54-43531

SEAL

16

01010-80820

BOLT

17

01643-30823

WASHER

|18

21W-54-43600

COVER ASS'Y

18

COVER

19

21W-54-43620

SEAL

20

01010-80820

BOLT

21

01643-30823

WASHER

|22

20U-54-43200

COVER ASS'Y

22

BOLT¤ WING

23

20P-54-71530

LOCK ASS'Y

24

20U-54-43220

COVER

25

21U-54-32340

CATCH

26

01010-D0820

BOLT

27

01643-70823

WASHER

28

21W-54-43450

COVER

29

01010-D0820

BOLT

30

01643-70823

WASHER

31

21W-54-43460

BRACKET

32

01010-80816

BOLT

|32

01010-80820

BOLT

33

01643-30823

WASHER

34

21W-54-43480

BRACKET

35

01010-81020

BOLT

|35

01010-80820

BOLT

36

01643-30823

WASHER

37

21W-54-43241

BRACKET

38

01010-81020

BOLT

39

01643-31032

WASHER

40

21W-54-43560

COVER

41

01010-80820

BOLT

42

01643-30823

WASHER
