Запчасти Komatsu PC78US-8 УПРАВЛЯЮЩ. КЛАПАН, ВНУТР. ЧАСТИ (/) (№88-) УПРАВЛЯЮЩ. КЛАПАН, ДЛЯ MACHINE БЕЗ ОТВАЛ

|$0

723-26-52202

Valve, Control

|$1

Body Group

|$2

Body Group

1

Spool

2

Plug

3

Orifice

4

Seal

5

O-ring

6

723-26-14650

Spring

7

723-26-16940

Flange

8

722-12-19120

O-ring

9

01252-60640

Bolt, Hexagon Socket Head

10

723-11-14350

Orifice

11

722-12-15160

Seal

12

07002-10823

O-ring

13

723-26-16350

Flange

14

723-11-19110

O-ring

15

723-26-16360

Sleeve

16

723-26-16371

Piston

17

723-26-16380

Spring

18

01252-60820

Bolt, Hexagon Socket Head

19

Case

20

723-11-19110

O-ring

21

Sleeve

22

723-26-16420

Retainer

23

Piston

24

Valve

25

723-26-16450

Spring

26

01252-60855

Bolt, Hexagon Socket Head

27

708-8E-16160

Plug

28

07002-11023

O-ring

29

Plug

30

723-26-16460

Plug

31

07000-11007

O-ring

32

07001-01007

Ring, Back-up

33

07000-12120

O-ring

34

07000-12020

O-ring

35

723-26-15840

O-ring

36

07000-11008

O-ring

37

07000-11006

O-ring

38

723-26-16920

Case

39

722-12-19120

O-ring

40

01252-60640

Bolt, Hexagon Socket Head
