Запчасти Komatsu PC78US-8 РУКОЯТЬ, РУКОЯТЬ И ПАЛЕЦ (№-) РУКОЯТЬ, MM, С -ДОПОЛН. АКТУАТОР ТРУБЫ

|$0

21W-973-0273

Arm Assembly

|$1

21W-973-0272

Arm Assembly

|$2

21W-973-0271

Arm Assembly

1

Arm

1

Arm

1

Arm

2

21W-70-41361

Bushing

3

20X-70-22140

Bushing

4

21W-70-51340

Bushing

4

21W-70-41621

Bushing

5

07020-00000

Fitting, Grease

6

07020-00900

Fitting, Grease

7

21W-62-44230

Hose

8

201-943-6121

Elbow

9

01010-81060

Bolt

10

01643-31032

Washer

11

56B-54-11272

Pin

12

21W-62-42440

Nipple

13

02896-11012

O-ring

14

07002-12034

O-ring

15

21W-62-42530

Elbow

16

02896-11012

O-ring

17

07002-12034

O-ring

18

21W-70-44321

Pin

19

205-70-66580

Plate

20

01010-81230

Bolt

21

01643-31232

Washer

22

21Y-70-14770

Spacer, T=1.0mm

23

07020-00000

Fitting, Grease

24

22P-70-11311

Pin

25

205-70-66580

Plate

26

01010-81230

Bolt

27

01643-31232

Washer

28

22C-70-31510

Spacer, T=1.0mm

29

07020-00000

Fitting, Grease

30

07145-00060

Seal, Dust

31

21W-70-41430

Seal

32

130-09-12931

Seal

33

21W-62-51660

Tube

|$39

21W-62-51660

Tube

|$40

21W-62-51660

Tube

|$41

21W-62-51660

Tube

|$42

21W-62-51660

Tube

34

21W-62-51670

Tube

|$44

21W-62-51670

Tube

|$45

21W-62-51670

Tube

|$46

21W-62-51670

Tube

|$47

21W-62-51670

Tube
