Запчасти Komatsu PC78US-8 МЕХАНИЗМ ПОВОРОТА И МОТОР, МОТОР ПОВОРОТА (/) (№8-) МЕХАНИЗМ ПОВОРОТА И МОТОР

|$0

21W-26-51020

Swing Machinery Assembly

1

201-26-81120

Case

1

21W-26-51120

Case

2

21W-26-41160

Shaft

3

21W-26-41240

Bearing

4

07012-00075

Seal, Oil

5

21W-26-41230

Bearing

6

21W-26-41281

Spacer

7

21W-26-41290

Seal

8

21W-26-51140

Elbow

9

07002-12434

O-ring

10

07040-11612

Plug

11

07002-11623

O-ring

12

21W-26-41180

Carrier

13

21W-26-41250

Pin

14

20S-26-71250

Pin, Spring

15

21W-26-41140

Gear

16

09232-02525

Bearing, Needle

17

201-26-71270

Washer, Thrust

18

04064-02512

Ring, Snap

19

21W-26-41270

Washer, Thrust

20

21W-26-41170

Carrier

21

201-26-71220

Shaft

22

21W-26-41120

Gear

23

424-15-12580

Bearing

24

21W-26-41260

Washer, Thrust

25

21W-26-41111

Gear

26

21W-26-41130

Gear

27

21W-26-52610

Gear, Ring

28

07049-01620

Plug

29

04020-01638

Pin, Dowel

30

07020-00000

Fitting, Grease

31

21W-26-51611

Plate

32

21W-26-51370

Hose

33

07238-10208

Connector

34

07283-32738

Clip, Pipe

35

01597-01009

Nut

36

01643-31032

Washer
