Запчасти Komatsu PC78US-8 КАПОТ, КАПОТ ЩИТКИ (№-) КАПОТ, ДЛЯ СТРАН ЕС

1

22P-54-11211

Hood

2

22P-54-12770

Hinge

3

01010-81020

Bolt

4

01643-31032

Washer

5

22P-54-11222

Cover

6

01010-81020

Bolt

7

01643-31032

Washer

8

22P-54-11983

Bracket

8

22P-54-11982

Bracket

9

01010-81025

Bolt

9

01010-81020

Bolt

10

01643-31032

Washer

11

22P-54-11181

Lock Assembly

11

22P-54-11180

Lock Assembly

12

01010-81020

Bolt

13

01643-31032

Washer

14

22P-54-12830

Cover

15

20Y-54-11611

Stopper

16

01580-11008

Nut

17

22P-54-12440

Seal

18

22P-54-12450

Seal

19

22P-54-12251

Sheet

20

22P-54-12261

Sheet

21

22P-54-12271

Sheet

22

22P-54-12292

Sheet

22

22P-54-12290

Sheet

23

22P-54-12381

Sheet

24

22P-54-12391

Sheet

25

22P-54-12890

Frame

26

01010-81020

Bolt

27

01643-31032

Washer

28

01010-80820

Bolt

29

01643-30823

Washer

30

22P-54-12840

Cover

31

09817-A0753

Plate, Warning, High Temperature

32

01010-80820

Bolt

33

01643-30823

Washer

34

22P-54-12930

Bracket

35

01010-81020

Bolt

36

01643-31032

Washer

37

21W-54-51420

Sheet

38

21W-54-51430

Sheet

39

21W-54-51440

Sheet
