Запчасти Komatsu PC78US-8 АККУМУЛЯТОР (№-79) АККУМУЛЯТОР

1

08001-2080D

Battery, Wet, 80D26L

1

08000-00000

Terminal, (+)

1

08000-00001

Terminal, (-)

2

22P-06-11121

Bracket

3

22P-06-11550

Bracket

4

22B-06-21450

Bolt

5

419-43-17920

Washer

6

22P-06-11131

Sheet

7

22P-06-11820

Plate

8

01010-81225

Bolt

9

01643-31232

Washer

10

08028-48030

Cable, Ground

11

01010-81045

Bolt

12

01643-31032

Washer

13

195-33-11220

Spacer

14

08038-22009

Cap, Terminal

15

22P-06-11680

Cable

16

08038-42009

Cap, Terminal

17

20U-06-21680

Cover, Terminal

18

08028-GH050

Cable, Ground

19

14X-06-12280

Cover

20

08038-04030

Cap, Terminal

21

04434-51712

Clip

22

01010-81220

Bolt

23

01643-31232

Washer

24

21W-06-51141

Cable

25

08038-00035

Cap, Terminal

26

08038-04030

Cap, Terminal

27

04434-51712

Clip

28

01010-81220

Bolt

29

01643-31232

Washer

30

04434-52512

Clip

31

07095-20318

Cushion

32

22P-06-11540

Grommet

33

04434-51712

Clip

34

01010-81220

Bolt

35

01643-31232

Washer
