Запчасти Komatsu PC78US-8 ЦИЛИНДР КОВША, ВНУТР. ЧАСТИ (№-) ЦИЛИНДР КОВША

|$0

707-00-0H752

Cylinder Assembly

|$1

707-00-0H751

Cylinder Assembly

1

721-11-90320

Cylinder

2

02896-11012

O-ring, (Kit : K06)

3

721-58-55180

Rod, Piston

4

707-76-50851

Bushing

5

07145-00050

Seal, Dust, (Kit : K06)

6

07020-00000

Fitting, Grease

7

707-76-60691

Bushing

8

21W-70-41440

Seal, Dust, (Kit : K06)

9

707-29-90310

Head, Cylinder

10

707-56-55740

Seal, Dust, (Kit : K06)

11

07179-12069

Ring, Snap

12

707-51-55211

Packing, Rod, (Kit : K06)

13

707-52-15310

Bushing

14

07000-12090

O-ring, (Kit : K06)

15

07000-12085

O-ring, (Kit : K06)

16

07146-02086

Ring, Back-up, (Kit : K06)

17

707-36-90240

Piston

18

707-44-90180

Ring, Piston, (Kit : K06)

19

07156-00912

Ring, Wear, (Kit : K06)

20

707-67-39020

Nut

21

707-86-46941

Tube

21

707-86-46940

Tube

22

02896-11012

O-ring, (Kit : K06)

23

707-86-46950

Tube

24

02896-11012

O-ring, (Kit : K06)

25

01010-81020

Bolt

26

01643-31032

Washer
