Запчасти Komatsu PC78US-8 ЦИЛИНДР РУКОЯТИ, ВНУТР. ЧАСТИ (№-) ЦИЛИНДР РУКОЯТИ, БЕЗ РУКОЯТЬ ANTI-DROP КЛАПАН

|$0

707-00-0H740

Cylinder Assembly

1

707-11-10H50

Cylinder

2

02896-11012

O-ring, (Kit : K05)

3

02896-11015

O-ring, (Kit : K05)

4

721-58-60740

Rod, Piston

5

707-76-55531

Bushing

6

07145-00055

Seal, Dust, (Kit : K05)

7

707-76-60711

Bushing

8

07145-00060

Seal, Dust, (Kit : K05)

9

707-71-70750

Plunger

10

707-71-60100

Plunger

11

04260-00635

Ball, Steel

12

707-71-91280

Cap

13

707-29-10342

Head, Cylinder

14

707-56-60740

Seal, Dust, (Kit : K05)

15

07179-12074

Ring, Snap

16

07177-06030

Bushing

17

707-51-60211

Packing, Rod, (Kit : K05)

18

07146-02096

Ring, Back-up, (Kit : K05)

19

07000-12095

O-ring, (Kit : K05)

20

07000-12100

O-ring, (Kit : K05)

21

707-35-91050

Ring, Back-up, (Kit : K05)

22

707-36-10420

Piston

23

707-44-10180

Ring, Piston, (Kit : K05)

24

07156-01012

Ring, Wear, (Kit : K05)

25

707-67-42020

Nut

26

707-86-48590

Tube

27

02896-11012

O-ring, (Kit : K05)

28

07283-32236

Clip, Pipe

29

01643-31032

Washer

30

01597-01009

Nut
