Запчасти Komatsu PC78US-8 МОТОР ХОДА И КОНЕЧНАЯ ПЕРЕДАЧА, ВНУТР. ЧАСТИ, МОТОР ХОДА (/) (№-) МОТОР ХОДА И КОНЕЧНАЯ ПЕРЕДАЧА

|$0

22P-60-11301

Motor Assembly

|$1

TZ119D1000-00

Final Drive Assembly

|$2

TZ192-230-30BA

Floating Seal Assembly, (Kit : K01)

1

Seal

2

TZ115D1001-00

Hub

3

TZ115D1002-00

Spindle

4

TZ111D1003-00

Carrier

5

TZ111D1004-00

Gear, Sun

6

TZ111D1005-00

Gear, Planetary

7

TZ110D1006-00

Gear, Sun

8

TZ110D1007-00

Gear, Planetary

9

TZ400G1009-00

Collar

10

TZ110D1010-00

Washer, Thrust

11

TZ110D1011-00

Washer, Thrust

12

TZ440D1012-00

Washer, Thrust

13

TZ110D1013-00

Cover

14

TZ110D1022-00

Nut, Ring

15

TZ110D1024-00

Bearing

16

TZ110D1027-00

Bearing

17

TZ110D1028-00

Bearing

18

TZ110D1029-00

Ring

19

TZ110D1030-00

Ring

20

TZ410D1033-01

Plug

21

07000-05230

O-ring, (Kit : K01)

22

07000-12014

O-ring, (Kit : K01)

23

TZ810B2021-00

Plug

24

TZ1180082010L2

Bolt

25

04260-00952

Ball

26

TZ263B2077-01

Pin, Dowel

27

07000-11007

O-ring, (Kit : K01)

28

TZJW1516-G37-7

O-ring, (Kit : K01)

29

TZ810B1018-00

Ring

30

TZJB1177M812-B

Screw, Hexagon Socket Head

31

04064-04518

Ring, Snap

32

TZ1180102010L

Bolt
