Запчасти Komatsu PC78US-8 ПРОПОРЦИОНАЛЬН. PRESSURE УПРАВЛ-Е (PPC) КЛАПАН ТРУБЫ, ОСНОВН. ТРУБЫ (/) (№-) ПРОПОРЦИОНАЛЬН. PRESSURE УПРАВЛ-Е (PPC) КЛАПАН ТРУБЫ, ДЛЯ MACHINE С SHIFT PATTERN (ISO/ЭКСКАВАТ.) КЛАПАН СЕЛЕКТОРА, ДЛЯ MACHINE С

1

21W-62-53520

Hose

1

21U-62-34760

Band, Red

2

21W-62-51150

Hose

2

21U-62-34730

Band, Green

2

21U-62-34710

Band, Yellow

3

21W-62-51150

Hose

3

21U-62-34740

Band, Orange

3

21U-62-34710

Band, Yellow

4

21W-62-51140

Hose

4

21U-62-34780

Band, Brown

5

21W-62-51121

Hose

5

21U-62-34740

Band, Orange

6

21W-62-51110

Hose

6

21U-62-34710

Band, Yellow

7

21W-62-53170

Hose

7

21U-62-34750

Band, Blue

7

21U-62-34710

Band, Yellow

8

20U-62-22190

O-ring

|$18

21W-60-43200

Valve Assembly

9

21W-62-43930

Nipple

10

21W-62-44750

Body

11

21W-62-42940

Nipple

12

07002-11423

O-ring

13

02896-11008

O-ring

14

21W-62-51280

Hose

14

21U-62-34730

Band, Green

14

21U-62-34750

Band, Blue

15

21W-62-41610

Hose

15

21U-62-34750

Band, Blue

16

21W-62-41521

Hose

16

21U-62-34730

Band, Green

17

21W-62-41521

Hose

17

21U-62-34720

Band, Black

18

21W-62-41451

Hose

18

21U-62-34720

Band, Black

18

21U-62-34710

Band, Yellow

19

21W-62-41451

Hose

19

21U-62-34780

Band, Brown

19

21U-62-34710

Band, Yellow

20

02760-00220

Hose

21

21W-62-53271

Hose

21

21U-62-34760

Band, Red

21

21U-62-34720

Band, Black

22

20U-62-22190

O-ring

|$44

21W-60-43200

Valve Assembly

23

21W-62-43930

Nipple

24

21W-62-44750

Body

25

21W-62-42940

Nipple

26

07002-11423

O-ring

27

02896-11008

O-ring

28

21W-62-51330

Hose, Yellow-Yellow

29

21W-62-51320

Hose, Green-Red

30

21W-62-51310

Hose, Red-Yellow

31

02761-00204

Hose, Face Seal Type
