Запчасти Komatsu PC78US-8 АККУМУЛЯТОР, (№-79) АККУМУЛЯТОР, С АККУМУЛЯТОР DISCONNECT ПЕРЕКЛЮЧАТЕЛЬ

1

08001-2080D

Battery, Wet, 80D26L

1

08000-00000

Terminal, (+)

1

08000-00001

Terminal, (-)

2

22P-06-11121

Bracket

3

22P-06-11550

Bracket

4

22B-06-21450

Bolt

5

419-43-17920

Washer

6

22P-06-11131

Sheet

7

22P-06-11820

Plate

8

01010-81225

Bolt

9

01643-31232

Washer

10

08028-58030

Cable, Ground

11

01010-81045

Bolt

12

01643-31032

Washer

13

195-33-11220

Spacer

14

22P-06-11680

Cable

15

08038-42009

Cap, Terminal

16

20U-06-21680

Cover, Terminal

17

08028-GH050

Cable, Ground

18

14X-06-12280

Cover

19

08038-04030

Cap, Terminal

20

04434-51712

Clip

21

01010-81220

Bolt

22

01643-31232

Washer

23

21W-06-51141

Cable

24

08038-00035

Cap, Terminal

25

08038-04030

Cap, Terminal

26

04434-51712

Clip

27

01010-81220

Bolt

28

01643-31232

Washer

29

04434-52512

Clip

30

07095-20318

Cushion

31

22P-06-11540

Grommet

32

04434-51712

Clip

33

01010-81220

Bolt

34

01643-31232

Washer

35

08038-22009

Cap, Terminal

36

22P-06-12340

Cable

37

04434-51712

Clip

38

01010-81225

Bolt

39

01643-31232

Washer

40

22P-06-12330

Bracket

41

01010-81025

Bolt

42

01643-31032

Washer

43

08038-00035

Cap, Terminal

44

08068-00001

Switch, Battery

45

01252-60825

Bolt, Hexagon Socket Head

46

01643-30823

Washer
