Запчасти Komatsu PC78US-8 РУКОЯТЬ, ДОПОЛН. ГИДРОЛИНИЯ (№-) РУКОЯТЬ, MM, С -ДОПОЛН. АКТУАТОР ТРУБЫ

1

21W-973-4640

Hose

2

21W-973-4630

Hose

3

21W-973-4471

Tube

4

21W-973-4491

Tube

5

22B-62-19410

Clamp

6

01010-81270

Bolt

7

01643-31232

Washer

8

203-62-43380

Cushion

9

203-62-43390

Cushion

9

203-973-5803

Valve Assembly

10

07000-13031

O-ring

11

04025-00412

Pin, Spring

12

04064-03015

Ring, Snap, for Shaft Side

13

203-973-3913

Body

14

203-973-3923

Shaft

15

07000-13025

O-ring

16

203-973-6610

Plate

17

01010-80825

Bolt

18

01643-30823

Washer

19

21T-72-14930

Boss

20

01010-81020

Bolt

21

01643-31032

Washer

22

22B-973-2150

Elbow

23

07002-13334

O-ring

24

22B-973-2120

Plug

25

21W-973-4550

Nipple

26

21W-973-4560

Nipple

27

07002-13334

O-ring

28

02896-11012

O-ring

29

02896-11018

O-ring

30

21W-973-4610

Tube

|$31

21W-973-4610

Tube

|$32

21W-973-4610

Tube

|$33

21W-973-4610

Tube

31

21W-973-5350

Tube

|$35

21W-973-5350

Tube

|$36

21W-973-5350

Tube

|$37

21W-973-5350

Tube
