Запчасти Komatsu PC78US-6 ГИДР. БАК. ГИДРАВЛИКА

|1

21W-60-00251

TANK ASS'Y

|1

21W-60-00250

TANK ASS'Y

1

21W-60-43111

TANK,HYDRAULIC

|1

21W-60-41111

TANK,HYDRAULIC

2

201-60-65240

TUBE

3

203-60-31100

ELBOW ASS'Y

4

201-60-12172

FILLER NECK

5

20Y-60-21340

GASKET

6

01252-70516

BOLT

7

01601-20513

WASHER

8

21W-60-41170

VALVE ASS'Y

9

20X-60-22140

SPRING

10

21W-60-41121

ELEMENT

11

21W-60-41290

COVER

|11

201-60-62150

COVER

12

07000-12135

O-RING

13

01010-81025

BOLT

14

01643-31032

WASHER

15

07270-00871

TUBE

|15

07270-00878

TUBE

16

07285-00095

CLIP

17

201-60-12191

CAP ASS'Y

18

21W-60-43130

COVER

|18

21W-60-41130

COVER

19

07000-12145

O-RING

20

01010-81035

BOLT

21

01643-31032

WASHER

22

12R-60-11230

SPRING

23

21W-60-43140

ROD

|23

21W-60-41140

ROD

24

21W-60-41150

STRAINER ASS'Y

25

07044-12412

PLUG

26

07002-12434

O-RING

27

07043-70617

PLUG

28

21W-60-43120

PLATE

29

20U-98-31320

PLATE

30

21X-54-32350

CAP

|30

07049-01215

PLUG

31

01010-81230

BOLT

32

01643-31232

WASHER

33

21W-60-41192

BRACKET

|33

21W-60-41191

BRACKET

34

01010-81020

BOLT

35

01643-31032

WASHER

36

203-54-63230

CLAMP

|36

203-54-63230

CLAMP

37

01023-10610

SCREW

|37

01023-10610

SCREW
