Запчасти Komatsu PC78US-6 МАРКИРОВКА (СПЕЦ-Я ДЛЯ РАЗРУШ. ЗДАНИЙ) (YELНИЗ.) МАРКИРОВКА

1

09690-M0063

PLATE¤ MARK,KOMATSU

1A

21W-54-46350

SEAL

2

21W-98-44130

PLATE¤ MARK,MACHINE MODEL

3

21W-98-44110

PLATE¤ MARK,MACHINE MODEL

4

09690-P0800

PLATE¤ MARK,KOMATSU

5

09690-P0400

PLATE¤ MARK,KOMATSU

|5

09690-P0450

PLATE¤ MARK,KOMATSU

5A

20U-98-31320

PLATE,OIL LEVEL

6

09133-A1680

PLATE¤ SAFETY,KEEP OUT OF TURNING AREA

7

09601-10001

PLATE¤ NAME,(LIMITED SUPPLY)

|7

09601-10000

PLATE¤ NAME,(LIMITED SUPPLY)

8

04418-13060

SCREW

9

21U-98-21250

PLATE¤ CAUTION,IF WINDOW IS BROKEN OR BECOMES

10

09134-A0880

PLATE¤ SAFETY,KEEP OUT OF WORKING AREA

10A

09971-00090

PLATE,FREON COLLECT/DESTRUCTION LAW

11

21W-98-41340

PLATE¤ OPERATING,JIS PATTERN

12

21W-98-41111

PLATE¤ CAUTION,ARARM ASS'Y PLATE

13

21W-98-44160

PLATE,STRUCTURE STANDARD

14

21W-98-44180

OIL CHART

|14

21W-98-41510

OIL CHART

15

21W-98-41310

PLATE¤ INSTRUCTION,AIR CLEANER

16

22B-00-11370

PLATE¤ SAFETY,SWING PARKING BRAKE

|16

21W-98-41180

PLATE¤ SAFETY,SWING PARKING BRAKE

17

09653-A0480

PLATE¤ SAFETY,HOT OIL/WATER

18

09667-A0480

PLATE¤ SAFETY,REVOLUTION

19

09669-0000E

PLATE¤ CAUTION,FUEL INLET

|19

21W-98-21380

PLATE¤ CAUTION

20

09808-A0880

PLATE¤ SAFETY,BATTERY CABLE

21

21W-98-41330

PLATE,FULL

22

09657-A0880

PLATE¤ SAFETY,TRACK ADJUSTMENT

23

09963-00101

TAG,DO NOT OPERATE

24

21U-98-31150

PLATE¤ MARK,SLING POSITION

25

21U-98-31160

PLATE¤ MARK,LOCATION OF CENTER OF GRAVITY

26

21W-98-41211

PLATE¤ MARK,MACHINE BODY LIFT POSTURE

27

21W-98-44152

PLATE¤ MARK,FUSE BOX

|27

21W-98-44151

PLATE¤ MARK,FUSE BOX

|27

21W-98-44150

PLATE¤ MARK,FUSE BOX

28

09805-C0480

PLATE¤ SAFETY

28A

22B-54-17650

PLATE,CABIN WITH HEAD GUARD

29

09803-A0480

PLATE¤ SAFETY,LOCK WHEN OPEN WINDOW WARNING

30

22U-00-21170

DECAL,LOCK FOR FRONT LOWER WINDOW

|30

09970-00230

PLATE¤ MARK,GALEO
