Запчасти Komatsu PC78US-6 ОСНОВН. КЛАПАН (-КЛАПАН) (8/)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

723-26-51101

CONTROL VALVE

|$3

BODY GROUP

1

SPOOL

2

PLUG

3

ORIFICE

4

RING

5

O-RING

6

723-26-16330

SPRING

7

723-26-16340

FLANGE

8

722-12-19120

O-RING

9

01252-60625

BOLT

10

723-11-14350

ORIFICE

11

722-12-15160

RING

12

07002-10823

O-RING

13

723-26-16350

FLANGE

14

723-11-19110

O-RING

15

723-26-16360

SLEEVE

16

723-26-16371

PISTON

17

723-26-16380

SPRING

18

01252-60820

BOLT

19

CASE

20

723-11-19110

O-RING

21

SLEEVE

22

723-26-16420

RETAINER

23

PISTON

24

VALVE

25

723-26-16450

SPRING

26

01252-60855

BOLT

27

702-21-55620

PLUG

28

07002-11423

O-RING

29

708-8E-16160

PLUG

30

07002-11023

O-RING

31

PLUG

32

723-11-27280

PLUG

33

07002-10823

O-RING

34

723-26-16460

PLUG

35

07000-11007

O-RING

36

07001-01007

RING,BACK-UP

37

07000-12120

O-RING

38

07000-12020

O-RING

39

723-26-15840

O-RING

40

07000-11008

O-RING

41

702-21-54260

O-RING
