Запчасти Komatsu PC78US-6 МОТОР ПОВОРОТА (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$2

708-7S-00242

MOTOR ASS'Y

|$3

708-7S-00241

MOTOR ASS'Y

|$7

708-7S-01212

MOTOR SUB ASS'Y

|$8

708-7S-01211

MOTOR SUB ASS'Y

1

708-7S-21111

PLATE,SWASH

2

708-7S-21511

HOUSING

2

708-7S-21510

HOUSING

3

706-73-71450

PLUG

4

07002-11423

O-RING

5

709-25-11650

VALVE,CHECK

6

700-80-63230

SPRING

7

708-7S-21610

PLUG

8

07002-12434

O-RING

|$18

706-73-72710

VALVE SUB ASS'Y

9

706-73-72720

VALVE

10

706-73-72730

POPPET

11

706-73-72740

PLUG

12

706-73-72440

SPRING

13

708-7S-21620

PLUG

14

07002-12434

O-RING

15

07000-12145

O-RING

16

720-68-19610

PIN

17

01252-61245

BOLT

18

708-7S-22110

SHAFT

19

708-7S-22140

BEARING

20

708-7S-22150

BEARING

21

708-7T-12230

SEAL,OIL

22

708-7S-22310

COVER

23

07000-12055

O-RING

24

04065-06020

RING,SNAP

25

708-7S-23110

BLOCK,CYLINDER

26

708-7S-23210

PLATE,VALVE

27

720-68-19610

PIN

28

708-2L-23360

PIN

29

708-7S-13530

SPACER

30

708-7S-23510

SPRING

31

04065-03212

RING,SNAP

32

708-1S-13350

GUIDE,RETAINER

33

708-1S-13340

RETAINER,SHOE

34

708-7S-23310

PISTON SUB ASS'Y

35

708-7S-23410

PLATE,THRUST

36

708-7S-25130

PLATE

37

708-7S-25120

DISC

38

708-7S-25140

PISTON,BRAKE

39

07000-12130

O-RING

40

07000-12120

O-RING

41

708-7S-25150

SPRING
