Запчасти Komatsu PC78US-6 ЦИЛИНДР РУКОЯТИ(ВНУТР. ЧАСТИ) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

707-00-XX681

CYLINDER GROUP,(FINAL COATING)

G1

707-00-XA641

CYLINDER GROUP,(NATURAL YELLOW)

G1

707-00-XA640

CYLINDER GROUP,(NATURAL YELLOW)

|$4

707-00-0A641

CYLINDER ASS'Y,ARM

|$5

707-00-0A640

CYLINDER ASS'Y,ARM

1

707-11-10C80

CYLINDER

2

707-76-55531

BUSHING

2

707-76-55530

BUSHING

3

07145-00055

SEAL,DUST (KIT)

4

707-29-10341

HEAD,CYLINDER

5

07177-06030

BUSHING

6

707-51-60211

PACKING,ROD (KIT)

7

141-63-93270

SEAL,DUST (KIT)

8

07179-12074

RING,SNAP

9

07000-12095

O-RING (KIT)

10

707-35-91050

RING,BACK-UP (KIT)

11

07000-12100

O-RING (KIT)

12

07000-12095

O-RING (KIT)

13

07146-02096

RING,BACK-UP (KIT)

14

721-58-60430

ROD,PISTON

15

707-76-60711

BUSHING

15

707-76-60710

BUSHING

16

07145-00060

SEAL,DUST (KIT)

17

707-71-70750

PLUNGER

18

707-36-10420

PISTON

19

707-44-10180

RING,PISTON (KIT)

20

07156-01012

RING,WEAR (KIT)

21

707-71-60100

PLUNGER

22

04260-00635

BALL

23

707-71-91280

CAP

24

707-67-42010

NUT

25

02896-11012

O-RING (KIT)

26

02896-11015

O-RING (KIT)

27

707-86-46930

TUBE

28

07283-32236

CLIP

28

07283-22236

CLIP

29

01597-01009

NUT

29

01599-01011

NUT

30

01643-31032

WASHER

31

02896-11012

O-RING (KIT)

K

707-98-35310

SERVICE KIT,ARM CYLINDER
