Запчасти Komatsu PC78US-6 РУКОЯТЬ (ДЛЯ УДЛИНН. РУКОЯТИ) (YELНИЗ.)(№98-) РАБОЧЕЕ ОБОРУДОВАНИЕ

|$4

21W-943-0123

ARM ASS'Y

|$5

21W-943-0122

ARM ASS'Y

|$6

21W-943-0121

ARM ASS'Y

|$7

21W-943-0120

ARM ASS'Y,LONG

1

ARM

1

ARM (YELLOW)

1

ARM (YELLOW)

2

21W-70-41361

BUSHING

2

21W-70-41360

BUSHING

3

20X-70-22140

BUSHING

4

21W-70-41621

BUSHING

4

21W-70-41620

BUSHING

5

07020-00000

FITTING,GREASE

6

07020-00675

FITTING,GREASE

7

21W-70-44320NK

PIN

7

21W-70-44320SA

PIN (YELLOW)

8

205-70-66580

PLATE

9

01010-81230

BOLT

10

01643-31232

WASHER

11

21Y-70-14770

SPACER, 1.0MM

12

07020-00000

FITTING,GREASE

13

201-70-72241

PIN

14

04082-00212

LOCK

15

01010-81230

BOLT

16

01643-31232

WASHER

17

22C-70-31510

SPACER, 1.0MM

18

07020-00000

FITTING,GREASE

19

07145-00060

SEAL,DUST

20

21W-70-41430

SEAL,DUST

21

130-09-12931

SEAL,DUST

22

21W-62-44230

HOSE

23

201-943-6120

ELBOW

24

01010-81030

BOLT

25

01643-31032

WASHER

26

21W-62-42440

NIPPLE

27

02896-11012

O-RING

28

07002-12034

O-RING

29

21W-62-42530

ELBOW

30

02896-11012

O-RING

31

07002-12034

O-RING
