Запчасти Komatsu PC78US-6 ДЕМПФЕР(№-) КОМПОНЕНТЫ ДВИГАТЕЛЯ

1

201-01-71120

COUPLING

2

01010-81245

BOLT

3

01643-31232

WASHER

4

201-01-71110

CAGE

5

01010-81030

BOLT

6

01643-31032

WASHER

7

201-01-71130

SHAFT

8

06045-06010

BEARING

9

04064-05020

RING,SNAP

10

04065-08025

RING,SNAP

11

07040-11209

PLUG

12

07002-01223

O-RING

13

01010-81035

BOLT

14

01643-31032

WASHER

15

21W-01-21150

NIPPLE

16

07005-03016

SEAL, WASHER

17

07286-01641

HOSE

18

08017-22204

CONDUIT

19

07285-00200

CLIP

20

21W-01-41190

ELBOW

21

07030-00252

BREATHER

22

21W-01-31292

BRACKET

23

01010-81020

BOLT

24

01643-31032

WASHER

25

21W-01-41152

BRACKET

25

21W-01-41151

BRACKET

26

01010-81040

BOLT

26

01010-81045

BOLT

27

01643-31032

WASHER

28

01010-81045

BOLT

28

01010-81050

BOLT

29

01643-31032

WASHER

30

01643-31032

WASHER

31

21W-01-41330

SHEET

32

01010-81025

BOLT

33

01643-31032

WASHER

34

203-54-55660

COLLAR

35

21W-01-41223

TUBE

35

21W-01-41222

TUBE

36

07260-20932

HOSE

37

07285-00150

CLIP
