Запчасти Komatsu PC78US-6 P.P.C ОСНОВН. ЛИНИЯ (/) (ОТВАЛ)(№-) ГИДРАВЛИКА
№
Артикул
Название
Примечание
Количество
1
21W-62-41411
HOSE, 2010MM,BLUE-YELLOW
1
21U-62-34750
BAND, BLUE
1
21U-62-34710
BAND, YELLOW
2
20U-62-22190
O-RING
3
21W-62-41480
HOSE, 1860MM,ORANGE-YELLOW
3
21U-62-34740
BAND, ORANGE
3
21U-62-34710
BAND, YELLOW
4
21W-62-41480
HOSE, 1860MM,BLACK-GREEN
4
21U-62-34730
BAND, GREEN
4
21U-62-34710
BAND, YELLOW
5
21W-62-41771
HOSE, 1650MM
5
21U-62-34720
BAND, BLACK
5
21U-62-34730
BAND, GREEN
6
21W-62-41441
HOSE, 2050MM,BROWN
6
21U-62-34780
BAND, BROWN
7
21W-62-41521
HOSE, 2200MM,YELLOW
7
21U-62-34710
BAND, YELLOW
8
21W-62-41581
HOSE, 2270MM,ORANGE
8
21U-62-34740
BAND, ORANGE
9
21W-62-41610
HOSE, 2260MM,RED
9
21U-62-34760
BAND, RED
10
21W-62-41761
HOSE, 1460MM,BLACK-BLUE
10
21U-62-34720
BAND, BLACK
10
21U-62-34750
BAND, BLUE
11
21W-62-43380
NIPPLE
12
21W-62-42940
NIPPLE
13
02896-11008
O-RING
14
07002-11423
O-RING
15
08210-00606
SPIRAL TUBE
16
08210-01204
SPIRAL TUBE
17
08034-20536
BAND
18
21W-62-41421
HOSE, 1990MM,RED-BLACK
18
21U-62-34760
BAND, RED
18
21U-62-34720
BAND, BLACK
19
20U-62-22190
O-RING
20
21W-62-41451
HOSE, 1950MM,BROWN-YELLOW
20
21U-62-34780
BAND, BROWN
20
21U-62-34710
BAND, YELLOW
21
21W-62-41470
HOSE, 1930MM,BLACK-YELLOW
21
21U-62-34720
BAND, BLACK
21
21U-62-34710
BAND, YELLOW
22
21W-62-41551
HOSE, 2280MM,BLACK
22
21U-62-34720
BAND, BLACK
23
21W-62-41561
HOSE, 2290MM,GREEN
23
21U-62-34730
BAND, GREEN
24
21W-62-41590
HOSE, 2350MM,BLUE
24
21U-62-34750
BAND, BLUE
25
21W-62-43380
NIPPLE
26
21W-62-42940
NIPPLE
27
02760-00221
HOSE,WHITE
27
21U-62-34770
BAND, WHITE
28
02896-11008
O-RING
29
07002-11423
O-RING
30
08210-00606
SPIRAL TUBE
31
08034-20536
BAND
Выбрано товаров: 55
