Запчасти Komatsu PC78US-6 P.P.C ОСНОВН. ЛИНИЯ (/)(№-) ГИДРАВЛИКА

Схема запчастей Komatsu PC78US-6 - P.P.C ОСНОВН. ЛИНИЯ (/)(№-) ГИДРАВЛИКА
1
1
2
2
3
3
4
4
4
5
5
6
6
7
7
8
8
9
10
11
12
13
14
15
16
16
17
18
19
19
20
20
21
21
22
22
23
23
24
24
25
26
27
28
29
30
30
30
31
32
33
33
34

Артикул

Название

Примечание

Количество

1

21W-62-41480

HOSE, 1860MM,ORANGE-YELLOW

1

21U-62-34740

BAND, ORANGE

1

21U-62-34710

BAND, YELLOW

2

21W-62-41480

HOSE, 1860MM,GREEN-YELLOW

2

21U-62-34730

BAND, GREEN

2

21U-62-34710

BAND, YELLOW

3

21W-62-41771

HOSE, 1650MM,BLACK-GREEN

3

21U-62-34720

BAND, BLACK

3

21U-62-34730

BAND, GREEN

4

21W-62-41441

HOSE, 2050MM,BROWN

4

21U-62-34780

BAND, BROWN

5

21W-62-41521

HOSE, 2200MM,YELLOW

5

21U-62-34710

BAND, YELLOW

6

21W-62-41581

HOSE, 2270MM,ORANGE

6

21U-62-34740

BAND, ORANGE

7

21W-62-41610

HOSE, 2260MM,RED

7

21U-62-34760

BAND, RED

8

21W-62-41761

HOSE, 1460MM,BLACK-BLUE

8

21U-62-34720

BAND, BLACK

8

21U-62-34750

BAND, BLUE

9

20T-60-82320

POPPET

10

21W-62-42870

NIPPLE

11

21W-62-42950

NIPPLE

12

07002-11423

O-RING

13

21W-62-42940

NIPPLE

14

02896-11008

O-RING

15

07002-11423

O-RING

16

08210-00606

SPIRAL TUBE

17

08210-01204

SPIRAL TUBE

18

08034-00536

BAND

19

21W-62-41451

HOSE, 1950MM,BROWN-YELLOW

19

21U-62-34780

BAND, BROWN

19

21U-62-34710

BAND, YELLOW

20

21W-62-41470

HOSE, 1930MM,BLACK-YELLOW

20

21U-62-34720

BAND, BLACK

20

21U-62-34710

BAND, YELLOW

21

21W-62-45230

HOSE, 1950MM

22

21W-62-41551

HOSE, 2280MM,BLACK

22

21U-62-34720

BAND, BLACK

23

21W-62-41561

HOSE, 2290MM,GREEN

23

21U-62-34730

BAND, GREEN

24

21W-62-41590

HOSE, 2350MM,BLUE

24

21U-62-34750

BAND, BLUE

25

20T-60-82320

POPPET

26

21W-62-42870

NIPPLE

27

21W-62-42950

NIPPLE

28

07002-11423

O-RING

29

21W-62-42940

NIPPLE

30

02760-00221

HOSE,WHITE

30

21U-62-34770

BAND, WHITE

31

02896-11008

O-RING

32

07002-11423

O-RING

33

08210-00606

SPIRAL TUBE

34

08034-00536

BAND

Выбрано товаров: 54
