Артикул
Название
Примечание
Количество
|$3
708-3T-00217
PUMP ASS'Y
|$4
708-3T-00216
PUMP ASS'Y
|$5
708-3T-00215
PUMP ASS'Y
|$7
708-3T-01116
PUMP SUB ASS'Y
|$8
708-3T-01115
PUMP SUB ASS'Y
|$9
708-3T-01114
PUMP SUB ASS'Y
|$10
708-3T-04130
CYLINDER BLOCK ASS'Y
1
BLOCK,CYLINDER
2
PLATE,VALVE
3
708-1W-23130
SEAT
4
708-3T-13150
SPRING
5
04065-04218
RING,SNAP
6
708-3T-13351
GUIDE,RETAINER
7
708-3T-13360
PIN
8
708-3T-13340
RETAINER,SHOE
9
708-3T-13312
PISTON SUB ASS'Y
9
708-3T-13311
PISTON SUB ASS'Y
|$21
708-3T-04111
FLANGE ASS'Y
10
FLANGE
11
PLUG
12
708-3T-13421
BALL
13
708-3T-13412
CAM,ROCKER
13
708-3T-13411
CAM,ROCKER
14
708-3T-13451
STUD,BALL
15
04020-01024
PIN
16
01252-61235
BOLT
17
07000-B2012
O-RING
18
708-7T-51210
O-RING
19
708-3T-14222
PLUG
20
07000-12010
O-RING
21
01643-51232
WASHER
22
01582-11210
NUT
23
708-3T-14114
PISTON SUB ASS'Y
23
708-3T-14113
PISTON SUB ASS'Y
24
708-3T-14120
SPRING
25
708-3T-12150
IMPELLER
26
708-3T-12160
COUPLING
27
708-3T-12410
SCREW
28
01640-20508
WASHER
29
708-3T-12420
PLATE
30
708-3T-05110
SHIM KIT
30
SHIM, 0.1MM
30
SHIM, 0.15MM
30
SHIM, 0.2MM
30
SHIM, 0.5MM
31
708-23-12350
SCREW
Выбрано товаров: 46
