Запчасти Komatsu PC78US-5 P.P.C ОСНОВН. ЛИНИЯ (MULTIPLE PATTERN УПРАВЛ-Е) ГИДРАВЛИКА

1

21W-62-38400

VALVE ASS'Y

2

20U-62-23770

ELBOW

3

07002-11423

O-RING

4

07235-10210

ELBOW

5

07002-11423

O-RING

6

07230-20210

UNION

7

07002-11423

O-RING

8

20Y-62-22830

BAND¤ WHITE

|8

20Y-62-22830

BAND¤ WHITE

9

20U-62-23550

BAND¤ ORANGE

|9

20U-62-23550

BAND¤ ORANGE

10

20Y-62-22790

BAND¤ RED

|10

20Y-62-22790

BAND¤ RED

11

20Y-62-22820

BAND¤ BLUE

|11

20Y-62-22820

BAND¤ BLUE

12

20Y-62-22840

BAND¤ BLACK

|12

20Y-62-22840

BAND¤ BLACK

13

20Y-62-22850

BAND¤ GREEN

|13

20Y-62-22850

BAND¤ GREEN

14

20Y-62-22860

BAND¤ BROWN

|14

20Y-62-22860

BAND¤ BROWN

15

20Y-62-22810

BAND¤ YELLOW

|15

20Y-62-22810

BAND¤ YELLOW

16

21X-62-22260

HOSE,WHITE

17

21X-62-22260

HOSE,ORANGE

18

21X-62-22260

HOSE,RED

19

21X-62-22260

HOSE,BLUE

20

21X-62-22260

HOSE,BLACK

21

21X-62-22260

HOSE,BROWN

22

21W-62-33260

HOSE,GREEN

23

21W-62-33260

HOSE,YELLOW

24

08210-01201

SPIRAL TUBE

25

09822-00800

PLATE¤ OPERATING,SELECT VALVE

26

09822-00010

PLATE¤ SAFETY

27

09822-A1110

PLATE¤ OPERATING

28

09822-A1120

PLATE¤ OPERATING

29

09822-00020

CASE¤ PLATE

30

01010-81040

BOLT

31

01643-31032

WASHER

32

22F-98-11311

PLATE¤ CAUTION

33

20U-98-31160

PLATE,SHIFT PATTERN

34

08210-01201

SPIRAL TUBE
