Запчасти Komatsu PC78US-5 ГИДРОЛИНИЯ РУКОЯТИ И КОВША(НАВЕСН.ОБОРУД.) ГИДРАВЛИКА

1

07230-20522

UNION

2

203-62-56830

NIPPLE

3

07002-12434

O-RING

4

07230-20422

UNION

5

07002-12034

O-RING

6

21W-62-38540

HOSE¤ 2100MM

6

21W-62-31560

HOSE¤ 2300MM,BLUE

7

21W-62-38540

HOSE¤ 2100MM

|7

21W-62-31560

HOSE¤ 2300MM,ORANGE

8

21W-62-38560

HOSE¤ 2100MM

|8

21W-62-31570

HOSE¤ 2300MM,GREEN

9

21W-62-38550

HOSE¤ 2150MM

|9

21W-62-31211

HOSE¤ 2400MM,RED

9A

08210-01805

SPIRAL TUBE

10

20U-62-22911

PLATE

11

21W-973-3130

PLATE

12

20U-62-22931

PLATE

13

21W-62-23110

WASHER

14

01643-31232

WASHER

15

21W-62-22970

SHEET

16

21W-62-22810

SPACER

17

07000-02015

O-RING

18

01010-81040

BOLT

19

01643-31032

WASHER

20

01010-80860

BOLT

21

01643-30823

WASHER

22

07095-20420

CUSHION

23

07095-20523

CUSHION

24

07095-20627

CUSHION

25

20U-62-22940

CUSHION

26

20U-62-22460

CUSHION

27

08034-20519

BAND

|27

08034-20519

BAND

28

21W-62-31731

BRACKET

|29

21W-62-31860

CUSHION

29

01010-81220

BOLT

30

01643-31232

WASHER

31

21W-62-31742

BRACKET

|31

21W-62-31980

CUSHION

32

01010-81220

BOLT

33

01643-31232

WASHER

34

21W-54-38560

COVER

35

01010-81070

BOLT

36

01010-81030

BOLT

37

01643-31032

WASHER
