Запчасти Komatsu PC78US-5 P.P.C ОСНОВН. ЛИНИЯ (MULTIPLE PATTERN УПРАВЛ-Е) (I.S.O - J.D.) ГИДРАВЛИКА

1

22M-62-14100

VALVE ASS'Y

2

20U-62-23770

ELBOW

3

07002-11423

O-RING

4

07235-10210

ELBOW

5

07002-11423

O-RING

6

07230-20210

UNION

7

07002-11423

O-RING

8

07040-11409

PLUG

9

07002-11423

O-RING

10

20U-62-23550

BAND, ORANGE

10

20U-62-23550

BAND, ORANGE

11

20Y-62-22840

BAND, BLACK

11

20Y-62-22840

BAND, BLACK

12

20Y-62-22850

BAND, GREEN

12

20Y-62-22850

BAND, GREEN

13

20Y-62-22810

BAND, YELLOW

13

20Y-62-22810

BAND, YELLOW

14

21X-62-22260

HOSE, 200MM,ORANGE

15

21X-62-22260

HOSE, 200MM,BLACK

16

21W-62-33260

HOSE,GREEN

17

21W-62-33260

HOSE,YELLOW

18

08210-01201

SPIRAL TUBE

19

09822-00800

PLATE, OPERATING,SELECT VALVE

20

09822-00010

PLATE, SAFETY

21

09822-A1110

PLATE, OPERATING

22

09822-A1120

PLATE, OPERATING

23

09822-00020

CASE, PLATE

24

01010-81040

BOLT

25

01643-31032

WASHER

26

22F-98-11311

PLATE, CAUTION

27

20U-98-31160

PLATE,SHIFT PATTERN
