Запчасти Komatsu PC78US-5 ОСНОВН. КЛАПАН (-АКТУАТОР) (/8) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

723-28-10401

VALVE ASS'Y

|$3

723-27-00301

BODY GROUP

1

VALVE

2

ORIFICE

3

VALVE

4

VALVE

5

VALVE

6

723-26-50100

VALVE SUB ASS'Y

7

VALVE

8

723-26-51190

PISTON

9

VALVE

10

723-26-51290

PISTON

11

VALVE

12

723-26-51250

PISTON

13

723-26-14220

SPRING

14

723-26-14240

SPRING

15

723-26-14140

SPRING

16

723-26-15230

PLUG

17

723-26-15370

PLUG

18

07002-12434

O-RING

19

07000-13035

O-RING

20

07000-12020

O-RING

21

07000-12120

O-RING

22

07000-12010

O-RING

23

07000-12012

O-RING

24

VALVE

25

723-26-15220

PLUG

26

723-26-15610

PLUG

27

723-26-14150

SPRING

28

723-26-14380

SPRING

29

07002-11223

O-RING

30

723-26-15580

PLUG

31

709-25-11361

SPRING

32

709-25-11650

VALVE,CHECK

33

07000-12016

O-RING

34

723-60-22230

RING,BACK-UP

35

723-26-15490

SLEEVE

36

07002-11823

O-RING

37

07000-12012

O-RING

38

07001-02012

RING,BACK-UP

39

07000-12010

O-RING

40

07001-02010

RING
