Запчасти Komatsu PC78MR-6 ОСНОВН. КОНСТРУКЦИЯ (КОНСОЛЬ) (ПРАВ.)(№7-) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

22U-43-23111

PLATE

2

21W-06-41531

WIRING HARNESS

3

21W-43-41380

BRACKET

4

22U-43-23130

STAY

5

22U-06-22320

COVER

6

22U-43-23140

COVER

7

21W-43-41323

MOTOR ASS'Y

8

01023-60616

SCREW

9

22U-06-22470

KNOB

10

08086-20000

SWITCH

11

21W-43-41390

BRACKET

12

22U-06-22190

SWITCH,BUZZER

13

22U-06-22390

SWITCH,LIGHT

14

20Y-06-23920

CLAMP

15

08034-10414

BAND

16

01023-60410

SCREW

17

01023-60512

SCREW

18

01023-10508

SCREW

19

01023-10512

SCREW

20

01601-20513

WASHER,SPRING

21

22U-43-23251

SHEET

22

22U-43-23290

CLIP

23

01023-60620

SCREW

24

01023-70514

SCREW

25

22U-43-23210

COVER

26

21W-06-41540

SWITCH ASS'Y

27

22U-43-23230

COVER

28

21W-43-41520

FRAME

29

08059-00310

CLIP

30

01023-60616

SCREW

31

569-06-61960

RELAY

32

01435-00612

BOLT

33

01023-60410

SCREW

34

21W-54-44340

SEAL

35

22U-43-23711

COVER

36

01023-10614

SCREW

37

01643-30623

WASHER

38

01010-D1030

BOLT

39

01643-71032

WASHER
