Запчасти Komatsu PC78MR-6 ПРАВ. КРЫШКА(YELНИЗ.) (ЕС НОВ. NOISEПОНИЖАЮЩ. ARRANGEMENT )(№8-) ЧАСТИ КОРПУСА

|$2

21W-46-48180

COVER ASS'Y

1

01010-80620

BOLT

2

01643-30623

WASHER

3

01010-81020

BOLT

4

01643-31032

WASHER

5

01010-81225

BOLT

6

01643-31232

WASHER

7

01023-10410

SCREW

8

01023-10512

SCREW

9

01643-30823

WASHER

10

04052-10833

PIN,SNAP

11

08037-02512

GROMMET

12

20B-54-12210

SPRING

13

20R-54-11460

SPRING

14

21W-46-48112

COVER

15

21W-46-48121

COVER

16

21W-46-48151

HINGE

17

21W-46-41641

SEAL

18

21W-46-41660

GROMMET

19

21W-46-41670

BRACKET

20

21W-46-41711

LOCK ASS'Y

21

21W-46-48130

SEAL

22

21W-46-41750

LOCK ASS'Y

23

21W-46-41780

SHEET

24

21W-54-41361

ROD

25

566-54-11340

GROMMET

26

21W-46-48170

SHEET

27

01010-81230

BOLT

28

130-43-64260

COLLAR

29

01010-81270

BOLT

30

01643-31232

WASHER

31

113-03-21160

SEAT

32

515-02-11330

BUSHING

33

566-35-42430

PLATE

34

07000-12016

O-RING

35

01010-81240

BOLT

36

01643-31232

WASHER

37

419-54-11270

SPACER

38

566-35-42430

PLATE
