Запчасти Komatsu PC75UU-3 КАБИНА (С ВЕРХН. ЗАЩИТА) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$4

21W-54-00121

CAB ASS'Y,(HEAD GUARD)

|$5

21W-54-00120

CAB ASS'Y,(HEAD GUARD)

|$6

21W-54-00141

CAB ASS'Y,(HEAD GUARD) (RADIO LESS)

|$7

21W-54-00140

CAB ASS'Y,(HEAD GUARD) (RADIO LESS)

1

CAB ASS'Y

1

CAB

2

113-B44-1230

BOLT

3

01643-51032

WASHER

4

20T-54-84750

WINDOW,L.H., UPPER

5

20U-54-24971

DAM

6

20U-54-25151

TRIM

7

20T-54-84760

WINDOW,L.H., LOWER

8

20U-54-24981

DAM

9

20U-54-26521

WINDOW,REAR, LOWER

9

21W-54-34770

WINDOW,REAR, LOWER

9A

20U-54-26531

PLATE

10

20U-54-24991

DAM

11

20U-54-25161

TRIM

12

20U-54-25162

SEAL

13

20U-54-26560

LINING,REAR

13

20U-54-24862

LINING,REAR

13

20U-54-24861

LINING,REAR

14

20U-54-24872

LINING,L.H.

14

20U-54-24871

LINING,L.H.

15

20U-54-24882

LINING,R.H.

15

20U-54-24881

LINING,R.H.

16

20U-54-25542

COVER,REAR

16

20U-54-25541

COVER,REAR

17

20U-54-25170

SEAL

18

20T-54-75122

DUCT

18

20T-54-75121

DUCT

19

08059-00310

CLIP

19

21W-54-14690

CLIP

20

20U-54-24681

TAPE

21

20U-54-25140

STOPPER

22

20T-54-84960

SHEET,NONSKID

23

20U-54-24711

GLASS,R.H.

24

20U-54-24721

STRIP,WEATHER

25

20U-54-24733

WINDOW,ROOF

26

20U-54-24741

STRIP,WEATHER

27

20T-54-75210

GROMMET

28

08037-01008

GROMMET

29

08037-02512

GROMMET

30

09415-01008

CAP

30

09415-01008

CAP

31

09415-00706

CAP

32

01023-20412

SCREW

32

01220-40412

SCREW

33

01641-20405

WASHER

34

01023-20612

SCREW

34

01220-40612

SCREW

35

01641-20608

WASHER

36

01370-40412

SCREW
